The G30.5 wheels use a hookless, TSS (Tubeless Straight Side) rim profile with an internal width of 22 mm. The TSS profile has been reinforced with additional material to resist damage from impacts. To ensure proper seating between the rim and tubeless ready tires, they have been designed to strictly adhere to the ETRTO standards. This allows for easy tire setting and inflation with no risk of the tire coming off.

Features

• Maximum tire pressure for G30.5 TLR rims : 5 bar (72.5 PSI) or the maximum pressure stated on the tire if it is lower.
• The straight sides are thick to resist to impacts.
• Compatible with inner tubes in case of ampuncture.
• The rim is produced with a patented system by CORIMA called INTERNAL FOAM CORE OVERPRESSURE PROTECTION SYSTEM. In the case that air leaks around the valve core or rim tape during initial setup, this system allows air to be released through a check valve to avoid over pressurizing the rim.
• In the meantime the sealant liquid is being effective, the internal airleaks are forwarded and put out of the rim via a silicone check valve. With this system there is no overpressure possible and mechanical over-constraints in the rim’s structure (exploding risk).
• Reliability is further enhanced by the use of 24 stainless steel spokes for each wheel and with external spoke nipples for easy adjustment and maintenance.
• The wheels are built with DT Swiss 240 hubs featuring the new EXP freehub body and provides ultrasmooth and reliable performance.
• Despite the sturdy design, the G30.5 wheels weigh just 1,550 g a pair ( 725 g FR / 825 g RR ), including tubeless rim tape and valve.

Specifications

• 28" tubeless ready front
• Profile : 30.5MM
• Rim width : 28mm
• Axle : Thru axle Ø12 x 100mm
• Weight : 720 g
• Carbon weave : 3K
• Black Spokes : 24
• Rim ETRTO 622X22TSS
• Both tube type tires and TLR tires compatible
