Push the pace on climbs, let loose on the descents. This aluminium hardtail gives you a feel for the trail with balanced, confident handling and a plush suspension fork.

Features

• Proven alloy performance: ALUXX aluminium frameset is hand-built in-house by the world leader in aluminium engineering.
• Balance and stability: Frame geometry is designed to optimize the balance and roll-over capabilities of 29-inch wheels or the liveliness of 27.5-inch wheels (depending on frame size).
• XC control: Suspension fork offers either 80mm or 100mm of smooth travel for added XC control.

Specifications

• Sizes: 27.5: XS,S,M 29: S,M,L,XL,XXL
• Colours: Gloss Metallic Black/Muscat Blanc & Gloss Cobalt/Black Diamond
• Frame: ALUXX-grade aluminium, disc
• Fork: SR Suntour XCE, QR, steel steerer XS & S 27.5 80mm travel All other sizes 100mm travel
• Shock: N/A
• Handlebar: Giant Connect Trail, 31.8mm XS 27.5 730mm All other sizes 780mm
• Grips: Giant Sole-O
• Stem: Giant Sport, 7-degree
• Seatpost: Giant Sport, 30.9mm XS 27.5 300mm All other sizes 375mm
• Saddle: Giant custom
• Pedals: MTB caged
• Shifters: microSHIFT, 2x8
• Front Derailleur: microSHIFT FD-M282
• Rear Derailleur: Shimano RD-M3020
• Brakes: Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
• Brake Levers: Tektro HDC M275
• Cassette: Shimano Deore HG200, 12x32
• Chain: KMC 8.3
• Crankset: Shimano FC-M315, 22/36
• Bottom Bracket: cartridge
• Rims: Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
• Hubs: alloy, sealed bearing
• Spokes: Stainless steel, 14g
• Tyres: Kenda Booster 27.5 or 29x2.2", wire bead
• Extras: 2.4" max tyre size
• Weight: The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Geometry
