The name "E-Triton" has been synonymous with a sporty, dynamic e-bike for many years – and this is even more true for the 6.5.1 version with its perfectly dimensioned frame and integrated 500 Wh PowerTube battery. A congenial addition is the smooth Performance Line drive unit with 75 Nm of torque. And the other top components also promise first-class functionality for many years to come.

Features

• Sporty pedelec with Shimano Deore 10-speed LinkGlide transmission
• Smooth Bosch Performance Line system with integrated 500 Wh battery and Kiox 300 display
• Load-capable designed frame tubes made of aluminium 6061
• Air suspension fork with 63 mm of travel, lockout and thru-axle
• Precise Tektro Volans disc brakes

Specifications

• Frame: Aluminium 6061
• Fork: SR Suntour Mobie25-Air LOR
• Headset: Acros Blocklock Taper 1 1/8"-1.8"
• Brake front: Tektro Volans
• Brake rear: Tektro Volans
• Brake disc: Tektro TR180-45A
• Crankset: Oxygen E-Scorpo
• Motor sprocket: STEVENS E-MTB
• Derailleur rear: Shimano Deore Shadow
• Chain: Shimano CN-LG500
• Cassette: Shimano CS-LG400-10
• Pedals: ATB Alu Pro Reflex
• Engine: Bosch G3 Performance Line
• Battery: Bosch PowerTube 500
• Charger: Bosch 4A charger
• Hubs rear: Shimano Deore XT
• Hubs front: Shimano Deore XT
• Rims: Oxygen RM-26 Disc SL
• Tires: Schwalbe Marathon
• Handlebar: Oxygen E-Scorpo
• Stem: Oxygen Versa II, adjustable
• Saddle: Selle Royal ON Female
• Seatpost: Oxygen E-Scorpo
• Shift lever right: Shimano Deore
• Brake lever: Tektro HD-T532
• Display: Bosch Kiox 300
• Headlight: B M IQ-XS Friendly
• Taillight: B M Shine Evo
• Carrier: Racktime Shine Evo RTA rear rack
• Mudguards: SKS mudguards
• Kickstand: Pletscher Comp kickstand
• Bell: STEVENS D85 bell
• Weight: 27.6 kg
• Max. Rider's weight: 140 kg
• Color(s): Velvet Black | Redwood
• Sizes: F 46, 52, 56 cm
